5 -30
Main fuse box
②
Main fuse
z
Main fuse box is attached to the right side of the
engine.
z
There are two main fuses in the main fuse box.
z
Remove the cover from fuse box, and pull out
the relating main fuse. If necessary, replace it
with a genuine part.
Rated capacity for chassis : 60 A
Rated capacity for engine & ECU : 60 A
z
As the main fuses are parts to protect electric
system and wirings, if damaged, check if there is
any problem in the electric system. Contact your
authorized local dealer for check.
▶
If the main fuse is burn out often, contact your authorized local dealer to check the
problem.
▶
Do not use alternatives instead of the genuine fuse. And, do not connect electric
wire to the battery terminals directly. It may cause fire and serious injury.
Notice
Main fuse
60A : Engine & ECU
60A : Chassis
