3 -26
(5) Four wheel drive lever (4WD)
z This lever is used to engage/disengage the four
wheel drive (4WD).
z Before operating the 4WD lever, press the clutch
pedal and stop the tractor completely.
z Pull the 4WD lever upward for engaging 4WD.
z 4WD is very effective in the following cases.
- When increasing the towing power for heavy
work.
- In case of working in sandy soil.
- To prevent tractor from spinning in wet land.
Four wheel
drive lever
4WD
2WD
(6) Middle PTO lever (if fitted)
z This lever is used to engage/disengage the
middle PTO shaft (optional).
z Before operating the Middle PTO lever, place
the PTO switch in OFF position and wait until the
shaft is stopped completely.
z Pull the middle PTO lever upward to engage the
middle PTO gear.
z For further the middle PTO shaft, see section 4-
4-(2), “Power take-off(PTO) shaft”
Middle PTO lever
ON
