LS SV037iS5-4 User Manual

Chapter 7 - Options
160
AOC
R
S
T
G
U
V
W
FX
RX
BX
RST
JOG
P1
P2
P3
CM
VR
V1
5G
IM
3
phase
AC
input
BOC
A+
A-
B+
B-
FBA
FBB
GND
E
Encoder
GND
+5V
+5V
VCC
VCC
Sub-B
MCNFC
FWD Run/Stop
REV Run/Stop
Emergency stop
Fault reset
JOG
Multi-function
input 1
Common Terminal
I
Power supply for
speed signal
+12V 10mA
Speed signal input
0~10V(1 kohm)
Speed signal input
4~20mA (250ohm)
(Common for
VR, V1, I )
Potentiometer
1 kohm, 1/2W
I/O-12~14 :
Factory setting:
Multi-speed input
(Speed-L, M, H)
24 V
FM
5G
30A
30C
30B
AXA
AXC
Encoder signal
input
(Open collector)
Encoder
signal
output
12~15 V DC
input/output
terminal
Encoder
signal ground
Note) 1. : Main circuit, : Control circuit
2. External speed command: V1, I, and V1+I (Refer to Function list)
Shield
External
Power
Supply
2. Sub-B board with
Open collector type encoder
Multi-function
input 2
Multi-function
input 3
Maximum
current thru
PC: 5mA
*2
