LS SV037iS5-4 User Manual

Chapter 5 - Parameter List
58
5.2 Function 1 Group [FU1]
Keypad Display Setting Range
Code Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
FU1-00
Jump to Desired Code #
Jump code Not displayed
1 to 99 Not available
1 1 Yes
87
None 0
Forward Prev 1
FU1-03
Run Prevention Run Prev. 03
Reverse Prev 2
- None No 87
Linear 0
S-curve 1
U-curve 2
Minimum 3
FU1-05
Acceleration Pattern Acc. pattern 05
Optimum 4
- Linear No 87
Linear 0
S-curve 1
U-curve 2
Minimum 3
FU1-06
Deceleration Pattern Dec. pattern 06
Optimum 4
- Linear No 87
Decel 0
DC-brake 1
FU1-07
Stop Mode Stop mode 07
Free-run 2
- Decel No 88
FU1-08
14
DC Injection Braking
Frequency
DcBr freq 08 FU1-22 to 60 [Hz] 0.01
5.00 [Hz]
No
FU1-09
DC Injection Braking
On-delay Time
DcBlk time 09 0 to 60 [sec] 0.01
0.1 [sec]
No
FU1-10
DC Injection Braking
Voltage
DcBr value 10 0 to 200 [%] 1 50 [%] No
FU1-11
DC Injection Braking
Time
DcBr time 11 0 to 60 [sec] 0.1
1.0 [sec]
No
89
FU1-12
Starting DC Injection
Braking Voltage
DcSt value 12 0 to 200 [%] 1 50 [%] No
FU1-13
Starting DC Injection
Braking Time
DcSt time 13 0 to 60 [sec] 0.1
0.0 [sec]
No
90
FU1-14
Pre-excitation Time PreExTime 14 0 to 60 [sec] 0.1
1.0 [sec]
No 90
FU1-15
Hold Time Hold Time 15 0 to 1000 [ms] 1 1000 [ms]
No 91
FU1-16
Pre-excitation Current Flux Force 16 100 to 500 [%] 0.1
100.0 [%]
No 91
FU1-20
Maximum Frequency Max freq 20 40 to 400 [Hz] 0.01
60.00 [Hz]
No
FU1-21
Base Frequency Base freq 21 30 to FU1-20 0.01
60.00 [Hz]
No
FU1-22
Starting Frequency Start freq 22 0.01 to 10 [Hz] 0.01
0.50 [Hz]
No
91
No 0
FU1-23
Frequency Limit selection
Freq limit 23
Yes 1
- No No
FU1-24
15
Low Limit Frequency F-limit Lo 24 0 to FU1-25 0.01
0.50 [Hz]
Yes
FU1-25
High Limit Frequency F-limit Hi 25 FU1-24 to FU1-20 0.01
60.00 [Hz]
No
92
Manual 0
FU1-26
Manual/Auto Torque
Boost Selection
Torque boost 26
Auto 1
- Manual
No
92
14
Code FU1-08 through FU1-11 appears only when FU1-07 is set to ‘DC-Brake’.
15
Code FU1-24 through FU1-25 appears only when FU1-23 is set to ‘Yes’.
