Chapter 5 - Parameter List
72
Keypad Display Setting Range
Code Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
EXT-19
Frequency Output
Corresponding to Pulse
Input Minimum
Frequency
F freq y1 19 0 to FU1-20 0.01
0.00 [Hz]
Yes
EXT-20
Pulse Input Maximum
Frequency
F pulse x2 20 0 to 100 [kHz] 0.01
10.00 [kHz]
Yes
EXT-21
Frequency Output
Corresponding to Pulse
Input Maximum
Frequency
F freq y2 21 0 to FU1-20 0.01
60.00 [Hz]
Yes
139
EXT-22
P-Gain for ‘Sub-B’ PG P-gain 22 0 to 9999 1 3000 Yes
EXT-23
I-Gain for ‘Sub-B’ PG I-gain 23 0 to 9999 1 50 Yes
140
EXT-24
Slip Frequency for
‘Sub-B’ Board
PG Slip Freq 24 0 to 200 [%] 1 100 [%]
Yes
140
EXT-25
P-Gain for
(Sensored) Vector_SPD
ASR P-Gain 25 10 to 500 [%] 0.1
100.0 [%]
Yes
EXT-26
I-Gain for
(Sensored) Vector_SPD
ASR I-Gain 26 10 to 9999 [ms] 1 200 [ms]
Yes
EXT-27
Forward Torque Limit Trq + Limit 27 0 to 200 [%] 1 180 [%]
Yes
EXT-28
Reverse Torque Limit Trq - Limit 28 0 to 200 [%] 1 180 [%]
Yes
-
FDT-1 0
FDT-2 1
FDT-3 2
FDT-4 3
FDT-5 4
OL 5
IOL 6
Stall 7
OV 8
LV 9
OH 10
Lost Command 11
Run 12
Stop 13
Steady 14
INV line 15
COMM line 16
Ssearch 17
Step pulse 18
Seq pulse 19
Ready 20
Trv. ACC 21
Trv. DEC 22
MMC 23
Zspd Dect 24
EXT-30
Multi-Function Output
Terminal ‘Q1’ Define
Q1 define 30
Torq Dect 25
- FDT-1 Yes
140
