LS SV150iS5-4 User Manual

Chapter 5 - Parameter List
68
Keypad Display Setting Range
Code Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
I/O-90 Step Frequency 13 Step freq-13 90 50.00 [Hz]
Yes
I/O-91 Step Frequency 14 Step freq-14 91 40.00 [Hz]
Yes
I/O-92 Step Frequency 15 Step freq-15 92 30.00 [Hz]
Yes
Speed-L 0
Speed-M 1
Speed-H 2
XCEL-L 3
XCEL-M 4
XCEL-H 5
Dc-brake 6
2nd Func 7
Exchange 8
- Reserved - 9
Up 10
Down 11
3-Wire 12
Ext Trip-A 13
Ext Trip-B 14
iTerm Clear 15
Open-loop 16
Main-drive 17
Analog hold 18
XCEL stop 19
P Gain2 20
SEQ-L 21
SEQ-M 22
SEQ-H 23
Manual 24
Go step 25
Hold step 26
Trv Off.Lo 27
Trv Off.Hi 28
Interlock1 29
Interlock2 30
Interlock3 31
Interlock4 32
Speed-X 33
Reset 34
BX 35
JOG 36
FX 37
RX 38
Ana Change 39
Pre excite 40
Spd/Trq 41
I/O-93
Multi-Function Input
Terminal ‘RST’ Define
RST define 93
ASR P/PI 42
- Reset Yes
120
