Chapter 6 - Parameter Description [FU2]
113
PID Wiring Example
PID Control
Selection
Power
Supply
U
V
W
G
R
S
T
FX FWD Run/Stop
RX REV Run/Stop
P1
(
Setting:
Open
-
loop)
CM
Common Terminal
M
VR
Power for Speed Signal
(+12V, 10mA)
V1 Speed Signal Input
0-10V (1kohm)
I Reference Feed back
5G Common for VR, V1, I
0V 24V
Power
Supply
AC220V 50/60 Hz
(OUT)
(COM) (24V)
Feedback (4~20mA)
Set point
setting
PUMP
