Chapter 2 - Operation

2.5.3 Operation via Keypad

1. Check the LCD display when Power ON. Otherwise, change the setting indicated above.

2. Set the Ref. Freq to 60 Hz using PROG/ENT/SHIFT, ▲ keys. Setting freq is displayed during stop.

3. When pressing FWD/REV key, motor starts running and output freq and output current are displayed.

4. Press STOP/RESET key. Then motor decelerates to stop. Setting freq 60Hz is displayed.

DRV▶K/K 0.0 A

00 STP 0.00Hz

Setting: DRV-03 [Drive Mode (Run/Stop method)] = 0 (Keypad)

DRV-04 [Frequency Mode (Freq. setting method)] = 0 (Keypad-1)

DRV▶K/K 0.0 A

00 STP 60.00Hz

DRV▶K/K 5.0 A

00 FWD 60.00Hz

DRV▶K/K 0.0 A

00 STP 60.00Hz
