3-2 MegaRAID SAS RAID Controller Characteristics
Copyright © 2009 by LSI Corporation. All rights reserved.
Note: The SAS 9240-4i RAID controller does not contain the J5
connector, which supports ports 4–7. The SAS 9240-8i
RAID controller contains the J5 connector.
This subsection provides the board layout and connector and jumper
information for the RAID controller. Figure 3.2 shows the jumpers and
connectors on the SAS 9240-8i RAID controller.
Figure 3.1 Card Layout for the MegaRAID SAS 9240-8i RAID
Controller
Tabl e 3 . 2 describes the jumpers and connectors on the SAS 9240-4i and
9240-8i RAID controllers.
