CHAPTER 13 - SPECIFICATIONS
13.1 Technical data
z Input & output ratings: Single Phase 200V Class
z
z Input & output ratings: Three Phase 200V Class
SV ■■■iG5A –2 ■■ 004 008 015 022 037 040 055 075 110 150 185 220
Max capacity
1
[HP] 0.5 1 2 3 5 5.4 7.5 10 15 20 25 30
[kW] 0.4 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22
Output
ratings
Capacity [kVA]
2
0.95 1.9 3.0 4.5 6.1 6.5 9.1 12.2 17.5 22.9 28.2 33.5
FLA [A]
3
2.5 5 8 12 16 17 24 32 46 60 74 88
Max
Frequency
400 [Hz]
4
Max Voltage 3Φ 200 ~ 230V
5
Input
ratings
Rated Voltage 3Φ 200 ~ 230 VAC (+10%, -15%)
Rated
Frequency
50 ~ 60 [Hz] (±5%)
Cooling method N/C
6
Forced cooling
Weight [kg] 0.76 0.77 1.12 1.84 1.89 1.89 3.66 3.66 9.0 9.0 13.3 13.3
1) Indicates the maximum applicable motor capacity when using a 4-pole standard motor.
2) Rated capacity is based on 220V for 200V class and 440V for 400V class.
3) Refer to 13-4 when Carrier frequency setting (H39) is above 3kHz.
4) Max frequency setting range is extended to 300Hz when H40 (Control mode select) is set to 3
(Sensorless vector control).
5) Maximum output voltage cannot be higher than the input voltage. It can be programmable below
input voltage.
6) N/C: Natural Convention
SV ■■■iG5A –1 ■■ 004 008 015
Max capacity
1
[HP] 0.5 1 2
[kW] 0.4 0.75 1.5
Output
ratings
Capacity [kVA]
2
0.95 1.9 3.0
FLA [A]
3
2.5 5 8
Max Frequency
400 [Hz]
4
Max Voltage 3Φ 200 ~ 230V
5
Input
ratings
Rated Voltage 1Φ 200 ~ 230 VAC (+10%, -15%)
Rated Frequency
50 ~ 60 [Hz] (±5%)
Cooling method Forced cooling
Weight [kg]
0.77 1.12 1.84
