- 23 -
Save, Restore & Reset
Save, Restore & Reset
The MXD70 Series features the ability to save and restore the current configuration of a channel and its
associated setpoints, current outputs, and digital inputs, into either one of two save slots inside the
instrument. Alternatively the configuration can be saved and restored via an SD card inserted into the
unit, which allows the instruments configuration to be backed up. It also provides the ability to copy
the configuration from one instrument to another, providing that the input card type for each channel
is the same on the second instrument.
The save and restore menu also features the ability to reset either the whole instrument or each
channels configuration, user calibration; and it’s associated setpoints, current outputs and digital
inputs, back to their factory settings.
Main Menu
From the front screen press the menu button to
show the main menu options and select
Save/Restore.
/ – Select Option
EXIT
– Return to Front Screen
– Enter Option
Save / Restore Menu
Select the operation you wish to carry out.
/ – Select Option
EXIT
– Return to Main Menu
– Enter Option
Select Target
Select which channel or alternatively the whole unit.
/ – Select Option
EXIT
– Return to Save / Restore Menu
– Enter Option
To Next Page
