Tables
- 16 -
Modbus RS485 Interface
Operating Guide
Tables
Table 6 – Menu Header / Front Screen Secondary Reading Options
Value
Sensor/Type Variable Channel 1 Channel 2 Channel 3
Clear (do not show anything) 1327 1327 1327
Readingˆ 1328 1329 1330
Temperature 1331 1332 1333
Manual Temperature 1334 1335 1336
Auxiliary mA
Input
Current Input 1402 1403 1404
Conventional
Conductivity
Conductivity 1340 1341 1342
Resistivity 1349 1350 1351
TDS 1352 1353 1354
Dissolved
Oxygen
Saturation (%) 1363 1364 1365
Concentration (ppm) 1366 1367 1368
Oxygen (pO2) 1369 1370 1371
Mercury (mmHg) 1372 1373 1374
mg/l 1375 1376 1377
Current 1378 1379 1380
Pressure (Atm)* 1384 1385 1386
Pressure (Bar)* 1387 1388 1389
Pressure (kPa)* 1390 1391 1392
Pressure (mH20)* 1393 1394 1395
Pressure (psi)* 1396 1397 1398
Pressure (mmHg)* 1399 1400 1401
Royce Do Probe (mV) 1381 1382 1383
Electrodeless
Conductivity
Conductivity 1340 1341 1342
pH / Redox Electrode (mV) 1343 1344 1345
Temperature (°C)* 1408 1409 1410
Temperature (°F) * 1411 1412 1413
Temperature (K)* 1414 1415 1416
Suspended
Solids /
Turbidity
Ps 1405 1406 1407
Current
Output
Current Output 1 1357
Current Output 2 1358
Current Output 3 1359
Current Output 4 1360
Current Output 5 1361
Current Output 6 1362
Calculation Calculation 1 Result 1355
Calculation 2 Result 1356
*Only available for Front Screen Secondary Reading Configuration
ˆ Not available for Front Screen Secondary Reading Conguration
