Registers
Modbus RS485 Interface
Operating Guide
- 43 -
Registers
Electrodeless Conductivity Configuration Continued
4765 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 6
FLOAT Custom Curve 1
Conductivity Point 6
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5355 Channel 2
5955 Channel 3
4767 Get/Set Channel 1 Custom Curve 1
Solution Point 6
FLOAT Electrodeless Custom
Curve 1 Solution Point 6
Value
Value Dependant on
Custom Curve 1 Solution
Range
5357 Channel 2
5957 Channel 3
4769 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 7
FLOAT Custom Curve 1
Conductivity Point 7
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5359 Channel 2
5959 Channel 3
4771 Get/Set Channel 1 Custom Curve 1
Solution Point 7
FLOAT Electrodeless Custom
Curve 1 Solution Point 7
Value
Value Dependant on
Custom Curve 1 Solution
Range
5361 Channel 2
5961 Channel 3
4773 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 8
FLOAT Custom Curve 1
Conductivity Point 8
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5363 Channel 2
5963 Channel 3
4775 Get/Set Channel 1 Custom Curve 1
Solution Point 8
FLOAT Electrodeless Custom
Curve 1 Solution Point 8
Value
Value Dependant on
Custom Curve 1 Solution
Range
5365 Channel 2
5965 Channel 3
4777 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 9
FLOAT Custom Curve 1
Conductivity Point 9
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5367 Channel 2
5967 Channel 3
4779 Get/Set Channel 1 Custom Curve 1
Solution Point 9
FLOAT Electrodeless Custom
Curve 1 Solution Point 9
Value
Value Dependant on
Custom Curve 1 Solution
Range
5369 Channel 2
5969 Channel 3
4781 Get/Set Channel 1 Custom Curve 2
Conductivity
Range
INT Custom Solution Curve
2 Conductivity
Operating Range
1567 = 0-9.999 µS/cm
5371 Channel 2 1568 = 0-99.99 ms/cm
5971 Channel 3 1569 = 0-999.9 ms/cm
1570 = 0-9999 ms/cm
4782 Get/Set Channel 1 Custom Curve 2
Points
INT Number of Points for
Custom Solution Curve
2
1 to 9
5372 Channel 2
5972 Channel 3
4783 Get/Set Channel 1 Custom Curve 2
First Units
INT 1
st
Character of Custom
Curve 2 Units
Refer To Table 1
5373 Channel 2
5973 Channel 3
4784 Get/Set Channel 1 Custom Curve 2
Second Units
INT 2
nd
Character of Custom
Curve 2 Units
5374 Channel 2
5974 Channel 3
4785 Get/Set Channel 1 Custom Curve 2
Third Units
INT 3
rd
Character of Custom
Curve 2 Units
5375 Channel 2
5975 Channel 3
4786 Get/Set Channel 1 Custom Curve 2
Fourth Units
INT 4
th
Character of Custom
Curve 2 Units
5376 Channel 2
5976 Channel 3
4787 Get/Set Channel 1 Custom Curve 2
Fifth Units
INT 5
th
Character of Custom
Curve 2 Units
5377 Channel 2
5977 Channel 3
4788 Get Channel 1 Custom Curve 2
Sixth Units
INT 6
th
Character of Custom
Curve 2 Units
5378 Channel 2
5978 Channel 3
To Next Page
