LTH Electronics MXD70 Series User Manual

Registers
- 44 -
Modbus RS485 Interface
Operating Guide
Registers
Electrodeless Conductivity Configuration Continued
4789 Get/Set Channel 1 Custom Curve 2
Solution Range
INT Custom Solution Curve
2 Solution Operating
Range
1567 = 0-9.999
5379 Channel 2 1568 = 0-99.99
5979 Channel 3 1569 = 0-999.9
1570 = 0-9999
4790 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 1
FLOAT Custom Curve 2
Conductivity Point 1
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5380 Channel 2
5980 Channel 3
4792 Get/Set Channel 1 Custom Curve 2
Solution Point 1
FLOAT Electrodeless Custom
Curve 2 Solution Point 1
Value
Value Dependant on
Custom Curve 2 Solution
Range
5382 Channel 2
5982 Channel 3
4794 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 2
FLOAT Custom Curve 2
Conductivity Point 2
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5384 Channel 2
5984 Channel 3
4796 Get/Set Channel 1 Custom Curve 2
Solution Point 2
FLOAT Electrodeless Custom
Curve 2 Solution Point 2
Value
Value Dependant on
Custom Curve 2 Solution
Range
5386 Channel 2
5986 Channel 3
4798 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 3
FLOAT Custom Curve 2
Conductivity Point 3
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5388 Channel 2
5988 Channel 3
4800 Get/Set Channel 1 Custom Curve 2
Solution Point 3
FLOAT Electrodeless Custom
Curve 2 Solution Point 3
Value
Value Dependant on
Custom Curve 2 Solution
Range
5390 Channel 2
5990 Channel 3
4802 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 4
FLOAT Custom Curve 2
Conductivity Point 4
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5392 Channel 2
5992 Channel 3
4804 Get/Set Channel 1 Custom Curve 2
Solution Point 4
FLOAT Electrodeless Custom
Curve 2 Solution Point 4
Value
Value Dependant on
Custom Curve 2 Solution
Range
5394 Channel 2
5994 Channel 3
4806 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 5
FLOAT Custom Curve 2
Conductivity Point 5
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5396 Channel 2
5996 Channel 3
4808 Get/Set Channel 1 Custom Curve 2
Solution Point 5
FLOAT Electrodeless Custom
Curve 2 Solution Point 5
Value
Value Dependant on
Custom Curve 2 Solution
Range
5398 Channel 2
5998 Channel 3
4810 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 6
FLOAT Custom Curve 2
Conductivity Point 6
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5400 Channel 2
6000 Channel 3
4812 Get/Set Channel 1 Custom Curve 2
Solution Point 6
FLOAT Electrodeless Custom
Curve 2 Solution Point 6
Value
Value Dependant on
Custom Curve 2 Solution
Range
5402 Channel 2
6002 Channel 3
4814 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 7
FLOAT Custom Curve 2
Conductivity Point 7
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5404 Channel 2
6004 Channel 3
4816 Get/Set Channel 1 Custom Curve 2
Solution Point 7
FLOAT Electrodeless Custom
Curve 2 Solution Point 7
Value
Value Dependant on
Custom Curve 2 Solution
Range
5406 Channel 2
6006 Channel 3
