Registers
Modbus RS485 Interface
Operating Guide
- 45 -
Registers
Electrodeless Configuration Continued
4818 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 8
FLOAT Custom Curve 2
Conductivity Point 8
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5408 Channel 2
6008 Channel 3
4820 Get/Set Channel 1 Custom Curve 2
Solution Point 8
FLOAT Electrodeless Custom
Curve 2 Solution Point 8
Value
Value Dependant on
Custom Curve 2 Solution
Range
5410 Channel 2
6010 Channel 3
4822 Get/Set Channel 1 Custom Curve 2
Conductivity
Point 9
FLOAT Custom Curve 2
Conductivity Point 9
Value
Value Dependant on
Custom Curve 2
Conductivity Range
5412 Channel 2
6012 Channel 3
4824 Get/Set Channel 1 Custom Curve 2
Solution Point 9
FLOAT Electrodeless Custom
Curve 2 Solution Point 9
Value
Value Dependant on
Custom Curve 2 Solution
Range
5414 Channel 2
6014 Channel 3
4826 Get/Set Channel 1 TDS Factor FLOAT TDS Factor Value
* (Only available when
Units set to TDS)
0.50 to 0.90
5416 Channel 2
6016 Channel 3
4828 Get/Set Channel 1 Temperature
Input Sensor
INT Temperature Input
Sensor
1069 = PT1000
5418 Channel 2 1075 = Sensor Disabled
6018 Channel 3
4829 Get/Set Channel 1 Temperature
Units
INT Temperature Units 1040 = °C
5419 Channel 2 1041 = °F
6019 Channel 3
4830 Get/Set Channel 1 Temperature
Compensation
INT Temperature
Compensation
1042 = In
5420 Channel 2 1043 = Out
6020 Channel 3
4831 Get/Set Channel 1 Temperature
Compensation
Base*
INT Temperature
Compensation Base
*(Only available when
Temperature
Compensation set to In)
1044 = +20°C
5421 Channel 2 1045 = +25°C
6021 Channel 3
4832 Get/Set Channel 1 Temperature
Compensation
Slope
FLOAT Temperature
Compensation Slope
Value
*(Only available when
Temperature
Compensation set to In)
0 to 9.99%°C
5422 Channel 2
6022 Channel 3
4834 Get/Set Channel 1 Temperature
Compensation
Mode
INT Temperature
Compensation Mode
*(only available when
temperature
compensation set to in
and temperature sensor
type not set to disabled)
1046 = Auto
5424 Channel 2 1047 = Manual
6024 Channel 3
4835 Get/Set Channel 1 Manual
Temperature
Input*
FLOAT -4.0°F to 302.0°F
*(only available when
Temperature
Compensation set to In
and Temperature
Compensation Mode set
to Manual)
-20.0 °C to 150.0 °C
5425 Channel 2
6025 Channel 3
To Next Page
