Registers
Modbus RS485 Interface
Operating Guide
- 55 -
Registers
Dissolved Oxygen Input Calibration
.
Dissolved Oxygen Input Calibration
6600 Get/Set Channel 1 Cal Manual
Temperature
Input*
FLOAT Calibration Manual
Temperature Input
*(Only available when
Temp Compensation
Mode is set to Manual)
-20.0°C to 150.0°C
6980 Channel 2 -4.0°F to 302.0°F
7360 Channel 3
6602 Get/Set Channel 1 Cal Units INT Calibration Units 1099 = %sat
6982 Channel 2 1100 = Ppm
7362 Channel 3 1101 = pO2
1102 = Mmhg
1103 = Mg/litre
6603 Get/Set Channel 1 Manual
Pressure Input*
FLOAT Manual Pressure Input
*(Only available when
Pressure Compensation is
set to Manual)
Atm: 0 to 99.99
6983 Channel 2 Bar: 0 to 99.99
7363 Channel 3 Kpa: 0 to 9999
mH20: 0 to 999.9
Psi: 0 to 999.9
mmHg: 0 to 9999
6605 Get/Set Channel 1 Span Level
FLOAT Span Calibration Point
%sat: 0 to 999.99
6985 Channel 2 Ppm: 0 to 20
7365 Channel 3 pO2 : 0 to 999.99
Mmhg : 0 to 999.99
Mg/litre : 0 to 20
6607 Get/Set Channel 1 Auto Span INT Enable Auto span
Calibration
1076 = Yes
6987 Channel 2 1077 = No
7367 Channel 3
6608 Get Channel 1 Temperature
Offset*
FLOAT Temperature Offset
Value
*(Not available when
Temperature Sensor is set
to Disabled)
-25°C to +25°C
-13.0°F to 77.0°F
6988 Channel 2
7368 Channel 3
6610 Get Channel 1 Sensor
Condition
INT Sensor Condition
0 = Good
6990 Channel 2 1 = Fault
7370 Channel 3 2 = Span High
3 = Refill
6611 Get/Set Channel 1 Calibration
Access
INT Front screen Calibration
Access
1076 = Yes
6991 Channel 2 1077 = No
7371 Channel 3
6612 Get/Set Channel 1 Calibration
reminder
INT Calibration Reminder
1076 = Yes
6992 Channel 2 1077 = No
7372 Channel 3
6613 Get/Set Channel 1 Calibration
Interval*
FLOAT Calibration Interval
*(Only available when
Calibration Reminder set
to yes)
0 to 999 Days
6993 Channel 2
7373 Channel 3
6615 Get/Set Channel 1 Calibration
Alarm Date*
INT Calibration Alarm Date
Value
*(Only available when
Calibration Reminder set
to yes)
1 to 31 Day
6995 Channel 2
7375 Channel 3
