Registers
Modbus RS485 Interface
Operating Guide
- 65 -
Registers
Setpoint Configuration Continued
8008 Get/Set Setpoint 1 Low Value* FLOAT Trigger Low Value
*(Not available when
Trigger is set to High)
Value depends on input
channel assigned to
8088 Setpoint 2
8168 Setpoint 3
8248 Setpoint 4
8328 Setpoint 5
8418 Setpoint 6
8010 Get/Set Setpoint 1 Units INT Trigger Value Units Refer to Table 5
8090 Setpoint 2
8170 Setpoint 3
8250 Setpoint 4
8330 Setpoint 5
8420 Setpoint 6
8011 Get/Set Setpoint 1 Mode* INT Mode
*(Only available when
Trigger is set to High or
Low)
1156 = On/Off
8091 Setpoint 2 1157 = Pulse Proportional
8171 Setpoint 3 1158 = Time Proportional
8251 Setpoint 4
8331 Setpoint 5
8421 Setpoint 6
8012 Get/Set Setpoint 1 Cycle Time* INT Minutes element for
Setpoint Cycle Time
*(Only available when
Mode is set to Time
Proportional)
0 to 59 Minutes
8092 Setpoint 2
8172 Setpoint 3
8252 Setpoint 4
8332 Setpoint 5
8422 Setpoint 6
8013 Get/Set Setpoint 1 Cycle Time* INT Seconds element for
Setpoint Cycle Time
*(Only available when
Mode is set to Time
Proportional)
0 to 59 Seconds
8093 Setpoint 2
8173 Setpoint 3
8253 Setpoint 4
8333 Setpoint 5
8423 Setpoint 6
8014 Get/Set Setpoint 1 Prop Band* FLOAT Proportion Band Size
Value
*(Not available when
Mode is set to On/Off)
Value depends on input
channel assigned to
8094 Setpoint 2
8174 Setpoint 3
8254 Setpoint 4
8334 Setpoint 5
8424 Setpoint 6
8016 Get/Set Setpoint 1 Delay Time
Minutes*
INT Minutes element for
Setpoint Delay Time
*(Only available when
Mode is set to On/Off)
0 to 59 Minutes
8096 Setpoint 2
8176 Setpoint 3
8256 Setpoint 4
8336 Setpoint 5
8426 Setpoint 6
8017 Get/Set Setpoint 1 Delay Time
Seconds*
INT Seconds element for
Setpoint Delay Time
*(Only available when
Mode is set to On/Off)
0 to 59 Seconds
8097 Setpoint 2
8177 Setpoint 3
8257 Setpoint 4
8337 Setpoint 5
8427 Setpoint 6
