Registers
Modbus RS485 Interface
Operating Guide
- 67 -
Registers
Setpoint Configuration Continued
8035 Get/Set Setpoint 1 Channel Alarm
Condition*
INT Alarm mode
*(Only Available when
Input Source is set to
Alarm)
1137 = Disabled
8115 Setpoint 2 1138 = Sensor Error
8195 Setpoint 3 1139 = Dose Alarm
8275 Setpoint 4 1140 = Calibration
8355 Setpoint 5 1141 = Offline
8445 Setpoint 6 1142 = Any Error
1143 = Cleaning
1144 = Calibration Due
1145 = Gain Error
8040 Get/Set Setpoint 1 Cleaning
Duration –
Minutes*
INT Minutes element for
Cleaning Duration
*(Only Available when
Input Source is set to
Cleaning)
0 to 10 Minutes
8120 Setpoint 2
8200 Setpoint 3
8280 Setpoint 4
8360 Setpoint 5
8450 Setpoint 6
8041 Get/Set Setpoint 1 Cleaning
Duration –
Seconds*
INT Seconds element for
Setpoint Cleaning
Duration
*(Only Available when
Input Source is set to
Cleaning)
0 to 59 Seconds
(Min 5 Seconds when
minutes is 0)
8121 Setpoint 2
8201 Setpoint 3
8281 Setpoint 4
8361 Setpoint 5
8451 Setpoint 6
8042 Get/Set Setpoint 1 Cleaning
Interval –
Hours*
INT Hours element for
Cleaning Interval Time
*(Only Available when
Input Source is set to
Cleaning)
0 to 23 hours
8122 Setpoint 2
8202 Setpoint 3
8282 Setpoint 4
8362 Setpoint 5
8452 Setpoint 6
8043 Get/Set Setpoint 1 Cleaning
Interval –
Minutes*
INT Minutes element for
Cleaning Interval Time
*(Only Available when
Input Source is set to
Cleaning)
0 to 59 minutes
(Min 1 Minutes when hours
is 0)
8123 Setpoint 2
8203 Setpoint 3
8283 Setpoint 4
8363 Setpoint 5
8453 Setpoint 6
8044 Get/Set Setpoint 1 Cleaning
Mode*
INT Setpoint Cleaning Mode
*(Only Available when
Input Source is set to
Cleaning)
1080 = Online
8124 Setpoint 2 1081 = Offline
8204 Setpoint 3
8284 Setpoint 4
8364 Setpoint 5
8454 Setpoint 6
8045 Get/Set Setpoint 1 Cleaning
Recovery –
Minutes*
INT Minutes element for
Setpoint Cleaning
Recovery Time
*(Only available when
Cleaning Mode set to
Offline)
0 to 10 minutes
8125 Setpoint 2
8205 Setpoint 3
8285 Setpoint 4
8365 Setpoint 5
8455 Setpoint 6
To Next Page
