Registers
- 72 -
Modbus RS485 Interface
Operating Guide
Registers
Digital Input Configuration Continued
9505 Get/Set Digital IP 1 Current Output
Level
INT Digital Input Offline
Current Output Drive
Level
*(Not available when
Function is set to Switch
Setup or Range
Changing)
1130 = No Action
9525 Digital IP 2 1131 = Drive To 0mA
9545 Digital IP 3 1132 = Drive To 22mA
9565 Digital IP 4 1133 = Hold Level
9585 Digital IP 5 1134 = Drive to 4mA
9605 Digital IP 6
9625 Digital IP 7
9645 Digital IP 8
9506 Get/Set Digital IP 1 Setpoint* INT Digital Input Setpoint
*(Only available when
Function is set to
Cleaning or Initial
Charge)
1147 = Setpoint None
9526 Digital IP 2 1148 = Setpoint 1
9546 Digital IP 3 1149 = Setpoint 2
9566 Digital IP 4 1150 = Setpoint 3
9586 Digital IP 5 1151 = Setpoint 4
9606 Digital IP 6 1152 = Setpoint 5
9626 Digital IP 7 1153 = Setpoint 6
9646 Digital IP 8
