Registers
Modbus RS485 Interface
Operating Guide
- 75 -
Registers
Suspended Solids Front Screen Secondary Reading Configuration
9770 Get/Set Channel 1 Secondary
reading 1
INT Secondary reading 1 Refer To Table 6
9920 Channel 2
10070 Channel 3
9771 Get/Set Channel 1 Secondary
reading 2
INT Secondary reading 2
9921 Channel 2
10071 Channel 3
Front Screen Calculation Configuration
10150 Get/Set Calc 1 Calculation
Shown
INT Calculation Shown 1076 = Yes
10220 Calc 2 1077 = No
10151 Get/Set Calc 1 Character 1 INT Label First Character Refer To Table1 (excluding
symbols)
10221 Calc 2
10152 Get/Set Calc 1 Character 2 INT Label Second Character
10222 Calc 2
10153 Get/Set Calc 1 Character 3 INT Label Third Character
10223 Calc 2
10154 Get/Set Calc 1 Character 4 INT Label Fourth Character
10224 Calc 2
10155 Get/Set Calc 1 Character 5 INT Label Fifth Character
10225 Calc 2
10156 Get/Set Calc 1 Character 6 INT Label Sixth Character Refer To Table1 (excluding
symbols)
10226 Calc 2
10157 Get/Set Calc 1 Character 7 INT Label Seventh Character
10227 Calc 2
10158 Get Calc 1 Character 8 INT Label Eighth Character
10228 Calc 2
Calculation Front Screen Secondary Reading Configuration
10170 Get/Set Calc 1 Secondary
reading 1
INT Front Screen Secondary
reading 1
1356 = Clear
10240 Calc 2 1357 = Current Output A
10171 Get/Set Calc 1 Secondary
reading 2
INT Front Screen Secondary
reading 2
1358 = Current Output B
10241 Calc 2 1359 = Current Output C
1360 = Current Output D
1361 = Current Output E
1362 = Current Output F
Current Output Front Screen Configuration
10300 Get/Set
Trend 1 Current Output
Front Screen
INT Current Output Front
Screen Configuration
*(Not available when
more than one channel
or calculation is currently
being shown)
1213 = Disabled
10301 Trend 2 1214 = Current Output A
1215 = Current Output B
1216 = Current Output C
1217 = Current Output D
1218 = Current Output E
1219 = Current Output F
