Registers
- 78 -
Modbus RS485 Interface
Operating Guide
Registers
Data logging Live Trend Configuration
10520 Get/Set
Trend 1 Traces INT Traces Configuration 1690 = None
10545 Trend 2 1691 = 1 Trace
10570 Trend 3 1692 = 2 Traces
10521 Get/Set Trend 1 Interval Hours INT Trend Interval Minutes 0 to 23 Hours
10546 Trend 2
10571 Trend 3
10522 Get/Set Trend 1 Interval Minutes INT Trend Interval Minutes 0 to 59 Minutes
10547 Trend 2
10572 Trend 3
10523 Get/Set Trend 1 Interval
Seconds
INT Trend Interval Seconds 0 to 59 Seconds
10548 Trend 2
10573 Trend 3
10524 Get/Set Trend 1 Primary
Variable
INT Trace 1 (Left hand axis) Refer to Table 4
10549 Trend 2
10574 Trend 3
10525 Get/Set Trend 1 Primary Range INT Trace 1 Range
*(Only available when
the associated variable
has been set to Auto
Range)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10550 Trend 2
10575 Trend 3
10526 Get/Set Trend 1 Primary Start
Number
FLOAT Trace 1 Minimum Value Value Dependant on
Primary Variable
10551 Trend 2
10576 Trend 3
10528 Get/Set Trend 1 Primary End
Number
FLOAT Trace 1 Maximum Value
10553 Trend 2
10578 Trend 3
10530 Get/Set Trend 1 Secondary
Variable
INT Trace 2 (Right hand axis) Refer to Table 4
10555 Trend 2
10580 Trend 3
10531 Get/Set Trend 1 Secondary
Range
INT Trace 2 Range
*(Only available when
the associated variable
has been set to Auto
Range)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10556 Trend 2
10581 Trend 3
10532 Get/Set Trend 1 Secondary Start
Number
FLOAT Trace 2 Minimum Value Value Dependant on
Secondary Variable
10557 Trend 2
10583 Trend 3
10534 Get/Set Trend 1 Secondary End
Number
FLOAT Trace 2 Maximum Value
10559 Trend 2
10585 Trend 3
To Next Page
