Code 2169- Load Default Settings
CAUTION! This code clears calibration and other setup settings.
Consult factory prior to entering the load default settings mode.
The load default setting code is used to initialize the main board.
Default values loaded may not be the settings required for your application.
Press numeric keys 2169. Press ENTER key.
The indicator display will briefly flash when loading is complete.
Configure indicator to required specifications. Four-Point Calibration must be
done before the Single-Point calibration can be performed.
Code 6969 - Initialize Clock Chip
Initializes the clock on units equipped with the Time & Date option.
See Setup – Code 9085 to set time and date.
To initialize the clock:
Press keys 6969. Press ENTER key.
Units ordered with the Time & Date option are initialized before being shipped.
Code 9080 - Indicator Setup
Note: indicator setup has been performed at the factory. This section is provided in
the event that these settings need to be changed.
Press keys 9080. Press ENTER key.
Press CAL switch at the rear end of board
KGS ONLY
Calibrate and weigh in Kilograms only select YES.
Press DEL key to select mode.
Press ENTER key to accept the selected setting.
If changing mode (LB/KG to KGS ONLY) or (KGS ONLY to LB/KG) the
indicator MUST be reconfigured and Four-Point calibration MUST be done.
COUNTBY
Available counts by values are 1 2 5
Press DEL key to select Count-By value.
Press ENTER key to accept the selected setting.
DECIMAL POSITION
Available decimal positions are 0 1 2 3
Key in decimal positions value.
Press ENTER key to accept setting.
FIXED ZERO
Select YES to count by 10, 20, of 50’s.
Press DEL key to select the number of fixed zeroes.
Press ENTER key to accept setting.
Note: if there are decimals selected, the fixed zeros are not available.
CTBY 1 , 2 , 5
NUMBER = 2
SELECT DECIMAL
NUMBER = 0
