ZERO TRACK DIGITS
Numbers of graduations for zero tracking are:
.6 1 3
Press DEL key to select the motion delay setting.
Press ENTER key to accept setting.
End of Indicator Setup - Code 9080.
Enter another configuration code to review or change parameters or
Code 9081 – Four-Point Calibration
A Four-Point linearity calibration is generally not required after initial installation. Single-Point
calibration should be used. The Four-Point calibration may be required in the event of load cell
replacement or weight loads of increasing value are not linear.
Code 9083 - Configure Remote Inputs
Press keys 9083. Press ENTER key.
REMOTE INPUT 1
Functions available for Remote Input #1 are:
PRINT ACCUMULATE INHIBIT
SCALE ZERO PUSH-BUTTON TARE
Press DEL key to select function for Remote Input #1.
Press ENTER key to accept setting.
REMOTE INPUT 2
Functions available for Remote Input #2 are:
PRINT ACCUMULATE INHIBIT
SCALE ZERO PUSH-BUTTON TARE
Press DEL key to select function for Remote Input #2.
Press ENTER key to accept setting.
Code 9084 - Configure Print
Note: The RS232 data format is 8 data bits, 1 stop bit and No parity.
Data, Stop and Parity are not selectable.
Press keys 9084. Press ENTER key.
SELECT BAUD
Available baud rates are: 1200 2400 4800 9600
For IR or RF load cell cables set to 9600.
Press DEL key to select baud rate.
Press ENTER to accept setting.
# TOP LINE FEEDS
Set to print blank lines (feed paper down) prior to printing selected data fields.
Use the numeric keypad to enter the value of top line feeds.
Press ENTER key to accept setting.
SELECT TRACK #D
NUMBER = 1
# TOP LINE FEEDS
NUMBER = 2
