LTS DR2100A/AN Indicator
Calibration Verification
1.36. Press keys 9092.
Press ENTER key.
1.37. Tilt forks front-to-back until level and position truck so left-to-right is level.
FB = +0.0° (+/- 0.2°)
LR = +0.0° (+/- 0.2°)
Press ZERO SCALE key if necessary.
1.38. Lift known test load.
Tilt forks front-to-back until level and position truck so left-to-right is level.
FB = +0.0°(+/- 0.2°
LR = +0.0° (+/- 0.2°)
Reading in tolerance? Repeat Single-Point calibration if necessary.
1.39. Tilt forks forward 3 degrees and tip truck so level left-to-right.
FB = +3.0° (+/- 0.2°)
LR = +0.0° (+/- 0.2°)
Reading in tolerance? Repeat Out-of-Level calibration if necessary.
1.40. Tilt forks until level front-to-back and tip truck so right side up 3 degrees.
FB = +0.0° (+/- 0.2°)
LR = -3.0° (+/- 0.2°)
Reading in tolerance? Repeat Out-of-Level calibration if necessary.
1.41. Tilt forks backward 3 degrees and tip truck so level left-to-right.
FB = -3.0° (+/- 0.2°)
LR = +0.0° (+/- 0.2°)
Reading in tolerance? Repeat Out-of-Level calibration if necessary.
1.42. Tilt forks until level front-to-back and tip truck so left side up 3 degrees.
FB = +0.0° (+/- 0.2°)
LR = +3.0° (+/- 0.2°)
Reading in tolerance? Repeat Out-of-Level procedure if necessary.
