INSTALLATION OF LIGHT KIT (Fig. 5)
• NOTE: The light kit must be installed by a licensed electrician.
• Align the two slot screws of the motor part with the keyhole slots of the light kit bracket (3).
• Turn the light kit bracket anticlockwise until the slot screws are firmly at the end of the slots.
• Tighten the screw (2) and the 2 slot screws to secure the light kit bracket.
• Install the lamp (4) to the GX53 lamp holder (5). Do not exceed the maximum power rating.
INSTALLATION OF Non-Light decoration plate (Fig. 5 – 2 )
• Remove the lamp (6) from the GX53 lamp holder
• Install the Non-Light decoration plate (7) on the light lit bracket .
