Lucent Technologies MERLIN LEGEND Release 6.1 Pocket Reference

MERLIN LEGEND Communications System Release 6.1
Pocket Reference
555-661-116
Issue 1
August 1998
Page 92
Power Supply Unit Load Requirements
Power Supply Unit Load Requirements (continued)
Unit Load Rating of System Trunks, Telephones, and Adjuncts
* Unit loads are computed per trunk.
† Up to two DSS consoles (one DSS per MLX-28D or MLX-20L) can be
powered from each control unit carrier. For example, a 3-carrier system can
have 6 system operator positions, each with one DSS powered from the
control unit.
‡ The MFM is powered by an individual wall power unit located at the station.
Network Access Trunks*
Unit Load
DID 1.0
DS1 0.0
GS/LS 0.0
Tie 1.4
Telephones
MLX-5, MLX-5D .9
MLX-10, MLX-10D, and MLX-10DP 1.2
MLX-16DP 1.5
MLX-28D 1.7
MLX-20L 1.6
BIS-10 1.1
BIS-22 and BIS-22D 1.3
BIS-34 and BIS-34D 1.5
MLC-5 0.0
MDC 9000 0.0
MDW 9000 0.0
5-Button 0.8
10-Button Basic 1.1
10-Button HFAI 1.2
34-Button Basic 1.1
34-Button DLX 1.7
34-Button BIS 1.4
34-Button BIS/DIS 1.4
Single-line telephone 0.7
Optional Equipment
EICON board (CTI link interface in NetWare server) 0.0
EICON DIVA 2.0 board
(CTI link interface in Windows NT platform)
0.0
DSS console† 0.9
MFM‡ 1.3
General Purpose Adapter 1.0
Hands-Free Unit 1.0
Headset adapter 1.0
