Operating Manual V25/09.2019
Ventus / Ventus-X / V200A
Chapter 9 Installation 14
9 Installation
The sensor bracket is designed to be installed on the top of a mast with a diameter of 50mm or
2”.
The following tools are required for the installation:
Hexagon socket 4.0
Compass for aligning
Ventus
to the North
9.1 Fastening
Figure 3 Fastening to the Mast
Loosen nuts
Push the sensor onto the top of the mast from above
Align the sensor to the North
Tighten both nuts evenly and secure with locking varnish
