Operating Instructions
Smart Weather Sensor
G. Lufft Mess- und Re
geltechni
k GmbH, Fellbach
, Germany
109
19.6.5.5
Buffer
Assignment Additional M
easurement Command
s M5 / C5: Comp
ass
Device configured for m
easurem
ent values in metric
or US units:
Measurement Value
UMB
Channel
Min
Max
Unit
Buffer ‘0’
Compass (act)
510
0.0
359.
0
°
Example: Request
with M com
mand
0M5!
00001<CR><LF>
0D0!
0+348.0
<CR><LF>
Example: Request
with C comm
and
0C5!
000001<CR><LF>
0D0!
0+348.0
<CR><LF>
108
110
Table of Contents
Default Chapter
3
Table of Contents
3
1 Please Read before Use
5
Symbols Used
5
Safety Instructions
5
Designated Use
5
Incorrect Use
5
Warranty
5
Brand Names
5
2 Scope of Delivery
6
3 Order Numbers
7
Accessories
9
Spare Parts
9
Additional Documents and Software
9
4 Equipment Description
10
Air Temperature and Humidity
10
Air Pressure
10
Precipitation
11
Wet Bulb Temperature
11
Specific Enthalpy
11
Air Density
11
Wind
11
Compass
11
Heating
11
Global Radiation
11
Lightning Sensor
11
Leaf Wetness
11
External Rain Gauge
12
Sensor Technology (Example: WS600-UMB)
13
5 Generation of Measurements
14
Current Measurement (Act)
14
Minimum and Maximum Values (Min and Max)
14
Average Value (Avg)
14
Vectorial Average Value (Vct)
14
6 Measurement Output
15
Air and Dewpoint Temperature
15
Wind Chill Temperature
15
Humidity
15
Air Pressure
15
Wet Bulb Temperature
16
Specific Enthalpy
16
Air Density
16
Wind Speed
17
Wind Direction
17
Wind Measurement Quality
18
Compass
18
Precipitation Quantity - Absolute
19
Precipitation Quantity - Differential
19
Precipitation Intensity
19
Precipitation Type
20
Heating Temperature
20
Global Radiation
20
Leaf Wetness
21
Lightning Sensor
21
Service Messages
21
7 Installation
22
Fastening
22
North Alignment
23
Selecting the Installation Location
24
8 Connections
26
Supply Voltage
26
RS485 Interface
27
Connection to ISOCON-UMB (8160.UISO)
28
Use of Surge Protection (8379.USP)
28
Connection of the Leaf Wetness Sensor
28
Connection of External Temperature and Precipitation Sensors
28
9 Commissioning
29
10 Configuration and Test
30
Factory Settings
30
Configuration with the UMB-Config-Tool
30
Function Test with UMB-Config-Tool
36
Operating Modes of the Smart Weather Sensor
37
Operating Modes for Equipment Heating
39
11 Firmware Update
41
12 Maintenance
41
Maintenance of the Rain Gauge
42
13 Technical Data
43
Measuring Range / Accuracy
45
Drawings
48
14 EC Certificate of Conformity
59
15 Fault Description
60
16 Disposal
61
Within the EC
61
Outside the EC
61
17 Repair / Corrective Maintenance
61
Technical Support
61
18 External Sensors
62
Leaf Wetness Sensor WLW100
62
External Temperature and Precipitation Sensors
64
19 Appendix
66
Channel List Summary
66
Channel List Summary Per TLS2002 FG3
68
Communication in Binary Protocol
69
Communication in ASCII Protocol
72
Communication in Terminal Mode
75
Communication in SDI-12 Mode
78
Communication in Modbus Mode
119
Communication: XDR Protocol
129
20 List of Figures
141
