22
2. Removethetwoxingscrews"A"and
removetheprotectivecover"B".Todo
this,rstpulltheroundedrearedge
outwardsandthenbackwardsthrough
thehandgrip,astheedgesofthe
protectivecoveradjoiningthecylinder
bodyarekeptinplacebyguidegrooves.
Ifnecessary,loosenthehandgripand
moveitbackwardstoobtainsu󰀩cient
spacetopullitout.
3. Movethebladearmsontheuntilbolt
“E”iseasilyaccessible.
 Nowswitcho󰀨thedeviceand
removethebatteryorunplugthe
powersupplyfromthedevice.
Work steps:
1. Firstofall,carefullycleantherescueequipment.
CAUTION / PLEASE NOTE!
When operating the device with
thehandguardremoved,thereis
anincreasedriskofinjurycaused
bytheexposed,movingelements.
E
E
B
A
