Lukas S 700 E2 - Page 23

23
4. Firstremovethegrubscrew"G",then
thecentralboltnut"H"andthenpullout
thecentralpin"J".
6. Releasethexingscrews“K”and
removethem.Thehandle“L”cannowbe
pulledoutforwards.
NOTE:
Thetorquerequiredcanbetakenfromthesparepartslistofyourparticularunit.
7. Theworkstepsmustbecarriedoutinreverseordertotthenewparts.
5. Removethelockingrings“M”and
pushthepin“N”out.Youcanthen
pullouttheblades“O”andtheslide
plates“P”.
ATTENTION!
ApplyLUKASspecialgreasetoallslidingsurfaces!
