IMPAC pyrometers series IN 5 plus
26
14 Data format UPP
®
(Universal Pyrometer Protocol)
Via interface and a suitable communication software or via “Test” function of the InfraWin software (see 10.7
Basic s
ettings Æ Test) commands can be exchanged directly with the pyrometer.
Note:
The ONL/OFFL switch must be in the ONL position before adjusting the
following parameters via the software (see 8.2).
The data exchange occurs in ASCII format with the following transmission parameters:
The data format is: 8 data bits, 1 stop bit, even parity (8,1,e)
The device responds to the entry of a command with: output (e.g. the measuring value) + CR (Carriage Re-
turn, ASCII 13), to pure entry commands with “ok” + CR.
Every command starts with the 2-digit device address AA (e.g. “00”).
This is followed by 2 small command letters (e.g. “em” for emissivity), followed, if necessary for that com-
mand, by the ASCII parameter “X” and finished with CR. If this parameter “X” is omitted, then the device
answers with the current set parameter.
A „?“ after the small command letters answers with the respective settings (only at setting commands, not at
enquiry commands).
Example: Entry: “00em“ + <CR>
The emissivity setting (
ε) of the device with the address 00 is returned
Answer: “0970“ + <CR> means Emissivity = 97.0%
Description Command Parameters
Reading measuring value:
AAms Output: YYYYY
5-digit decimal, in
1
/
10
°C or. °F
88880 = temp. overflow
02563 = 256.3 °C or °F
-0170 = -17.0 °C or °F
Emissivity: AAemXX
AAemXXXX
XX = 20 to 99%, 00 = 100% (decimal)
XXXX = 0200 to 1000 in ‰
Exposure time t
90
: AAezX
X = 0 to 6 (decimal)
0 = intrinsic time constant of the device
1 = 0.5 s 3 = 2 s 5 = 10 s
2 = 1 s 4 = 5 s 6 = 30 s
Analog output
1)
: AAasX X = 0;1 0 = 0 - 20 mA 1 = 4 - 20 mA
Clear time of maximum /
minimum value storage:
AAlzX
X = 0 to 8 (decimal)
0 = maximum/minimum value storage off
1 = 0.10 s 5 = 5.00 s
2 = 0.25 s 6 = 25.00 s
3 = 0.50 s 7 = externally deleted
4 = 1.00 s 8 = automatically cleared
External clearing:
AAlx
Simulation of an external clearing contact
Changing °C / °F
1)
: AAfhX
X = 0;1 (decimal)
0 = Output Celsius
1 = Output Fahrenheit
Reading basic temperature
range:
AAmb
Output: YYYYZZZZ
8-digit hex in °C or °F
YYYY = beginning of temperature range
ZZZZ = end of temperature range
Reading sub range: AAme as with mb
Repeatedly reading
measuring values:
AAmsXXX XXX = 000 to 999
XXX = No. of measuring values
Laser targeting light: AAlaX
X = 0;1 (decimal)
0 = switch off pilot light
1 = switch on pilot light
