Series 6 – TV Advanced Manual Electrical Installation ∂ 9
2 Introduction
2.1 Technical Data
(Different from IS 6 Advanced, IGA 6 Advanced, IGA 6/23 Advanced, ISR 6 Advanced, or
IGAR 6 Advanced)
Video-Signal:
FBAS
-
Signal ca. 1 VSS at 75 Ohms,
PAL (B), 50 Hz, CCIR656
video output galvanically isolated from power supply, analog
output and digital interface
Date/Time:
Real time clock with about 14 days buffer (GoldCap)
Connection of Video
-
Signal:
Separate triaxial socket to support double shielded signal
transmission (at pyrometer)
BNC connector (on user side - BNC-RCA adapter included)
Video signal can be switched off via software
Operating ambient
temperature:
0 to 60
°C on the housing
Note: During operation the instruments will warm up and might reach an intrinsic
temperature of up to 58 °C.
Optics
Superimposed text elements: Circular target marker, user text, time, date, measured
temperature
Additional: device temperature or distance or serial no. or
intensity (only ISR)
Field of view:
approx
. 11.6% x 8.4
% of the adjusted measuring distance
Resolution
:
768 x 576 Pixel video chip
768 x 520 Pixel displayed on screen
Brightness control
:
Automatic or manual (via software)
Note: The calibration / adjustment of this pyrometer is carried out in accordance with
VDI/VDE 3511, Part 4.4. See http://info.lumasenseinc.com/calibration for more
information.
