IGA 320/23 Operating Manual Introduction
10
Uncertainty:
(with ε =1, t
90
=1 s, T
amb.
=23
°C)
up to 400 °C: 2 °C
above 400 °C: 0.3% of measured value in °C + 1 °C
above 1500 °C: 0.5% of measured value in °C
(Note: the pyrometer must be operate at least 30 min before these values are valid)
Repeatability:
(ε =1, t
90
=1 s, T
amb.
=23 °C)
0.1% of measured value in °C + 1 °C
Protection class:
IP65 (IEC 60529)
Ambient temperature:
0 to 70 °C on housing, T
meas.
at least 25 °C above T
housing
Storage temperature:
-20 to 70 °C
Rel. humidity:
No condensing conditions
Weight:
0.3 kg
Housing:
Stainless steel
Connector:
8 pin connector
Sighting:
Built-in LED targeting light
CE-label:
According to EU directives about electromagnetic immunity
Note: The determination of the technical data of this pyrometer is carried out in
accordance with VDI/VDE directive IEC TS 62942-2, ‘‘Determination of the technical
data for radiation thermometers’’.
The calibration / adjustment of the instruments was carried out in accordance with
VDI/VDE directive ‘‘Temperature measurement in industry, Radiation thermometry,
Calibration of radiation thermometers’’, VDI/VDE 3511, Part 4.4.
For additional details on this directive, see http://info.lumasenseinc.com/calibration
or
order the directive from ‘‘Beuth Verlag GmbH’’ in D-10772 Berlin, Germany.
2.4 Dimensions
Dimensions in mm
