LumaSense IMPAC IS 310 User Manual

IS 310 / IGA 310 Manual Reference Numbers
•
21
7 Reference Numbers
7.1 Reference numbers instrument
Pyrometer Optics
Temperature Range
650 … 1800 °C
(MB 18)
800 … 2300 °C
(MB 23)
1100 … 2500 °C
(MB 25)
IS 310
a = 250 mm 3 902 210 3 902 250 3 902 310
a = 600 mm 3 902 220 3 902 260 3 902 320
a = 1400 mm 3 902 230 3 902 270 3 902 330
Pyrometer Optics
Temperature Range
300 … 1300 °C
(MB 13L)
500 … 1500 °C
(MB 15)
IGA 310
a = 250 mm
3 902 050
3 902 110
a = 600 mm
3 902 060
3 902 120
a = 1400 mm
3 902 070
3 902 130
7.2 Reference numbers accessories
3 821 610
Connection cable IS 310 / IGA 310, 2 m
3 821 620
Connection cable IS 310 / IGA 310, 5 m
3 821 630
Connection cable IS 310 / IGA 310, 10 m
3 821 640
Connection cable IS 310 / IGA 310, 15 m
3 821 650
Connection cable IS 310 / IGA 310, 20 m
3 821 660
Connection cable IS 310 / IGA 310, 25 m
3 821 670
Connection cable IS 310 / IGA 310, 30 m
3 852 290
Power supply NG DC for carrier rail mounting housing
(100 ... 240 V AC, 50 ... 60 Hz ⇒ 24 V DC, 1 A)
3 852 280
Power supply, 230 V AC, 500 mA, => 24 V DC, for C/Z-carrier rail mounting
3 890 650
DA 4000, LED-display, 2-wire power supply, 2 limit switches (relay contacts),
230 V AC
3 891 220
DA 4000, LED-display, 2-wire power supply, 2 limit switches (relay contacts),
115 V AC
3 890 520
DA 6000, LED-display, RS232, 2-wire power supply, max. value storage, analog
output
3 890 530
DA 6000, LED-display with RS485
3 890 150
DA 6000-T, digital display, RS232, measures the time to cool from 800 °C to 500 °C
(for welding processes)
3 890 610
Galvanic separator for measuring output (carrier rail mounting housing)
3 826 760
Converter 4...20 mA into 0...20 mA, 24 V DC, for DIN Rail
3 834 230
Adjustable mounting support, stainless steel
3 846 170
Mounting tube
3 835 180
Air purge unit, stainless steel
3 837 480
Water cooling jacket series 310 & 320, stainless steel, with integrated air purge
unit
