Lumel P20 User Manual

17
Input parameters:
- resistance of voltage input [V] > 1 MW
- resistance of current input [mA] 12 W ±1%
Sustained overload:
- TC and RTD 1.1 X
n
- voltage, current and resistance 1.3 X
n
Short duration overload:
- voltage input 5 U
n
- current input 10 I
n
Ensured protection level
acc. to EN 60529:
- housing IP 40
- from terminal side IP 20
Dimensions: 22.5 ´ 100 ´ 120 mm
Weight: 0.125 kg
Fitting on a 35 mm DIN rail,
acc. to EN 60715
Electromagnetic compatibility:
- noise immunity EN 61000-6-2
- noise emission EN 61000-6-4
Safety requirements acc. to EN 61010-1:
- installation category III
- pollution degree 2
- phase-to-earth working voltage:
- supply 300 V
2)
- input 50 V
- output 50 V
- altitude above sea level < 2000 m
1)
A part of sub-ranges for thermocouples and RTD has a specied individual
class – see table 3
2)
Execution for supply voltage 230 V.

Lumel P20 Specifications

General

Brand	Lumel
Model	P20
Category	Transducer
Language	English
