1. APPLICATION
The P20 programmable transducer is designed to convert temperature,
resistance, voltage from a shunt and standard signals into a constant-
current or constant-voltage standard signal.
The output signal is galvanicaly isolated from the input signal and
supply.
The transducer compensates automatically the resistance of wires in
case of resistance value measurements in a three-wire system and au-
tomatically compensates the temperature of terminals in case of mea-
surements from thermocouples.
The transducer is fully configurable through the PD14 programmer. By
means of this programmer, one can change the input type, the measu-
rement averaging time and rescale the analog output acc. to the indivi-
dual output characteristic, and also read out the measured value.
2. TRANSDUCER SET
The set of the P20 transducer is composed of:
- P20 transducer 1 pc.
- User’s manual 1 pc.
- Plug with screw terminals 2 pcs.
- Hole plug of the programmer socket 1 pc
When unpacking the transducer, please check whether the type and
execution code on the data plate correspond to the order.
