Lumens VC-A71PN

41
3-2
Multicast Setting
(This function setting
applies to VC-A71PN)
The setting can be configured after Multicast is enabled
4
MPEG-TS Setting
1. Set MPEG-TS format
2. The port number must be set in the range above 1024 with a maximum
value of 9999
<Remark>The following port has been used by the camera. Setting of
the port may not connect correctly
8554, 8556, 8557, 8080, 80, 81, 9090, 23
<Remark> VC-A71PN does not support this setting
5
SRT Setting
1. Set the field of SRT and then check the item to open SRT streaming
After the SRT streaming is opened, it will be connected automatically
upon startup
2. The port number must be set in the range above 1024 with a maximum
value of 9999
The following port has been used by the camera. Setting of the port
may not connect correctly
8554, 8556, 8557, 8080, 9090, 1935
3. Delay time is for 20 to 8000 microseconds. The default value is 120
microseconds
<Remark> VC-A71PN does not support this setting
6
SNTP/ Port Setting
1. Set the SNTP server address
2. Set the HTTP port, and the default is Port 80
Set the HTTPS port, and the default is Port 81
<Remark> The settings can only be modified when the camera's DHCP
function is turned off
7
Tracking Data Output
Setting
When enabled, PTZ position information can be fed back when the
camera is moving
1. Serial port output: The protocol must be set to VISCA, and the baud
rate should be 38400
(For related settings, please refer to 6.2.14 Setting - Maintenance -
System Service)
2. IP output: It can set IP address and communication port
<Remark> The performance of the camera may be affected when
Tracking Data Output is enabled
