Lumiax Magicube Series User Manual

4.1 Characteristics of MC2010 Structure &
①Heat Sink
—dissipate controller heat
②Plastic Case
—Internal protection
③LED & LCD
— Display settings and operating status,
system parameters
④Key: MENU、OK
—Set and view the operating parameters
⑤Temperature Sensor Port
—Collect temperature information,
Temperature compensation.
⑥RJ11 interface
—Connecting monitoring devices
⑦ Load Terminals
—Connected load.
⑧Battery Terminals
—Connect the battery.
⑨Solar module terminals
—Connected solar modules.
①Heat Sink
—dissipate controller heat
②Plastic Case
—Internal protection
③LED & LCD
— Display settings and operating status,
system parameters
④Key: MENU、OK
—Set and view the operating parameters
⑤Temperature Sensor Port
—Collect temperature information,
Temperature compensation.
⑥RJ11 interface
—Connecting monitoring devices
⑦ Load Terminals
—Connected load.
⑧Battery Terminals
—Connect the battery.
⑨Solar module terminals
—Connected solar modules.
4.2 Characteristics of MC4010 Structure &
4, Structure & Accessory
③
④
⑧⑨ ⑦
①
②
⑤ ⑥
③
④
⑧⑨ ⑦
①
②
⑤ ⑥
5
