Lumiax MT1050 User Manual

③
④
⑧⑨ ⑦
MENU
OK
4.2 Characteristics of MT2075/2010/3075 Structure &
①Heat Sink
—dissipate controller heat
②Plastic Case
—Internal protection
③LCD
— Display settings and operating status,
system parameters
④Key: MENU、OK
—Set and view the operating parameters
⑤RJ11 interface
—Connecting monitoring devices
⑥Temperature Sensor Port
—Collect temperature information,
Temperature compensation.
⑦ Load Terminals
—Connected load.
⑧Battery Terminals
—Connect the battery.
⑨Solar module terminals
—Connected solar modules.
②
⑤
⑥
①
9

Lumiax MT1050 Specifications

General

Brand	Lumiax
Model	MT1050
Category	Controller
Language	English
