20
6.6.2 Battery setting
2.1 Bat. type : LIQ
2.2 Bat. Volt : AUTO
2.3 LVD : 11.2V
2.4 LVR : 12.0V
2.5 Equal volt : 14.8V
2.6 Boost Volt : 14.5V
2.7 Float volt : 13.7V
OK
If the cursor indicates "Battery setting", you can press OK and the
interface displayed as shown on the left.
2.1 Bat. type (Battery Type)
This item can change the battery type, press the OK key to enter the
menu, you may press to change the battery type.
Possibilities for programming: GEL, AGM, LIQ, LI.(default : GEL)
2.2 Bat. Volt (Battery Voltage)
This item suitable for Gel, AGM and LIQ battery, the controller can
be set to identify only fixed system voltage or automatically system
voltage.
Possibilities for programming: 12V, 24V, 48V, AUTO. (default : AUTO)
2.3 LVD (Low Voltage Disconnect)
This item can change the low voltage disconnect data, press the OK
key to enter the menu, you may press to change the value.
Possibilities for programming:
10.8~11.8V/21.6~23.6V/43.2~47.2V(default : 11.2V/22.4V/44.8V).
Possibilities for programming: 12V, 24V, 48V, AUTO.
2.4 LVR (Low Voltage Reconnect)
This item can change the low voltage reconnect data, press the OK
key to enter the menu, you may press to change the value.
Note: The solar charge controller allows the smallest difference
between LVD and LVR is 0.6/1.2/2.4V. If you want to program a high
level for disconnection you must first increase the reconnection level.
Possibilities for programming:
11.4~12.8V/22.8~25.6V/45.6~51.2V(default: 11.8V/23.6V/47.2V)
2.5 Equal volt (Equalization voltage)
This item can change the equalization voltage, press the OK key to
enter the menu, you may press to change the value.
Note: 1.The equalization charging can only be adjusted for batteries
with liquid electrolyte, since high equalising voltages are harmful for
sealed batteries. The maximum equalising voltage value should be
stated on the battery manufacturer's data sheet.
2.This window is deactivated if you have selected "GEL" battery.
Possibilities for programming:
14.0~15.0V/28.0~30.0V/56~60.0V(default: 14.8V/29.6V/59.2V)
2.6 Boost volt (Boost voltage)
This item can change the boost voltage, press the OK key to enter
the menu, you may press to change the value.
Possibilities for programming:
14.0~14.8V/28.0~29.6V/56.0~59.2V(default: 14.5V/29.0V/58.0V)
2.7 Float volt (Float voltage)
This item can change the float voltage, press the OK key to enter
the menu, you may press to change the value.
Possibilities for programming:
13.0~14.5V/26.0~29V/52.0~58.0V(default: 13.7V/27.4V/54.8V)
The battery type is
LiQ, AGM or GEL.
