2 SAFETY
Inappropriate or unauthorized use or failure to comply with the information contained in these instructions, voids any
warranty, and may invalidate the certificate. Modifications or changes to the equipment are not allowed.
The following must be observed by the installer and end user:
• national safety regulations
• national workplace health and safety regulations
• national installation and set-up regulations
• generally accepted engineering standards
• the safety information contained in these operating instructions
• the data and rated operating conditions
• disposal of waste, parts, or floodlight in accordance with national regulations
• the equipment is suitable for harmful or corrosive chemicals that may be present.
3 SPECIFICATIONS
3.1 INPUT AND ELECTRICAL
Input Voltage Range
24VDC (±10%)
Power consumption
3,2W
Current consumption
130mA (@ 24VDC)
Max number of connected luminaires over wired 0-10V
50
Max cable length to luminaires over wired 0-10V
100m - 2x0,75mm² shielded cable
3.2 PHYSICALS
LN1003552 CP2 Control Panel
Outer dimensions (Details in chapter 7)
100 x 70 x 74 mm (L W D)
Panel cutout (Details in chapter 4)
81 x 43 mm
Weight
0,27kg
LN1003873 CP2 Control Panel Large
Outer dimensions
100 x 100 x 74 mm (L W D)
Panel cutout (Details in chapter 4)
81 x 43 mm
Weight
0,3kg
3.3 COMPLIANCE
IACS E10 (Rev.7 Oct 2018)
EMC2 Class B Bridge and Open deck
CE and UKCA
Do not open when
energized.
