Lust CDA34.017 - Appendix A; Technical Data

A-2
CDA3000 Operation Manual
A.1 Technical data
CDA32.003 to CDA34.006
Designation
Technical data
CDA32.003 CDA32.004
CDA32.006 CDA32.008
CDA34.003
CDA34.005 CDA34.006
Output, motor side
Recommended rated power
with 4-pin standard motor
0.375 kW 0.75 kW 1.1 kW 1.5 kW 0.75 kW 1.5 kW 2.2 kW
Device rated power 1.0 kVA 1.7 kVA 2.3 kVA 3.0 kVA 1.6 kVA 3.0 kVA 4.2 kVA
Voltage 3 x 0 ... 230 V 3 x 0 ... 400/460 V
Continuous current (RMS) (I
N
)
2.4 A 4.0 A 5.5 A 7.1 A 2.2 A 4.1 A 5.7 A
Peak current 1.8 x I
N
for 30 s
4.3 A 7.2 A 9.9 A 12.8 A 4.0 A 7.4 A 10.3 A
Rotating field frequency 0 ... 1600 Hz (> 800 Hz switching frequency = 16 kHz recommended)
Switching frequency of power stage 4, 8, 16 kHz
Input, mains side
Mains voltage
1 x 230 V
-20 % +15 %
3 x 460 V
-25 % +10 %
Asymmetry of mains voltage – ±3 % max.
Frequency 50/60 Hz ±10 % 50/60 Hz ±10 %
Power loss 25 W 35 W 65 W 82 W 45 W 80 W 100 W
Braking chopper power electronics
Peak braking power with int.
braking resistor (only with version
CDA34 ..., Wx.x, BR)
––––
1.6 kW
at 360
Ω
Minimum ohmic resistance of an
externally installed braking resistor
100
Ω 56 Ω 180 Ω
