Lust CDA34.017 - 3.7.1 Choice of Terminal Assignment

CDA3000 Operation Manual
3-11
3 Electrical installation
1
2
3
4
5
A
DE
EN
FR
IT
ES
FR
3.7.1 Choice of termi-
nal assignment
Typical applications Commissioning/control mode Terminal assignment Continued on
• Project planning and commissioning are
already complete.
• Loading of an existing data set.
Production commissioning
Obtain the terminal
assignment from your
project engineer.
Seite 4-2
Commissioning
• Pump, fan and extruder drivers and
traction drives with low dynamics
• Multi-motor operation
Voltage Frequency Control (VFC)
Assignment 1
page 3-13
Assignment 2
page 3-14
• Dynamic traction, lifting and rotational
drives
• Applications with dynamic load
surges
Sensorless Flux Control (SFC)
- Only for asynchronous motor
Assignment 1
page 3-13
Assignment 2
page 3-14
• Dynamic traction, lifting and rotational
drives with speed control
• With encoder feedback
Field-Oriented Regulation (FOR)
- Only for asynchronous motor
Assignment 3
page 3-15
Assignment 4
page 3-16
Selection
