8. POWER SUPPLY from DC
ADAPTER
The meter also can supply the power supply from the
DC 9V Power Adapter ( optional ). Insert the plug of
Power Adapter into " DC 9V Power Adapter Input Socket "
( 3-13, Fig. 1 ).
The meter will permanent power ON when use the
DC ADAPTER power supply ( The power Button
function is disable ).
9. BATTERY REPLACEMENT
is necessary to replace the battery. However, in-spec.
measurement may still be made for several hours after
low battery indicator appears before the instrument
become inaccurate.
2)Loose the " Battery Cover Screws ", take away the "
Battery Cover " ( 3-14, Fig. 1 ) from the instrument
and remove the battery.
3)Replace with DC 1.5 V battery ( UM3, AA, Alkaline/heavy
duty ) x 8 PCs, and reinstate the cover.
4)Make sure the battery cover is secured after changing
the battery.
10. RS232 PC SERIAL INTERFACE
The instrument has RS232 PC serial interface via a 3.5
mm terminal ( 3-11, Fig. 1 ).
The data output is a 16 digit stream which can be
utilized for user's specific application.
22
