D8 to D1 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D0 End Word
RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
11. Optional Type K Temp. probe
(Type K) TP-01 * Measuring Range : -40 to 250 ℃
( -40 to 482 )℉
* Max. short-term operating Temp. :
300 ℃
* It's an ultra fast response naked-
bead thermocouple suitable for
many general purpose application.
Thermocouple * Measure Range: -50 to 900 ,℃℃
Probe -58 to 1650 .℉℉
(Type K), TP-02A * Dimension:12cm tube, 3.2mm Dia.
Thermocouple * Measure Range: -50 to 1100 ,℃℃
Probe -58 to 2012 .℉℉
(Type K), TP-03 * Dimension: 13.6cm tube, 8mm Dia.
Surface Probe * Measure Range: -50 to 400 ,℃℃
(Type K), TP-04 -58 to 752 .℉℉
* Size :
Temp. sensing head - 15 mm Dia.
Probe length - 120 mm.
24
