Frequency
Range 4 Hz/40 Hz/400 Hz/4 KHz/40 KHz/
400 KHz/4 MHz
Resolution 0.001 Hz/0.01 Hz/0.1 Hz/0.001 KHz/0.01 KHz
0.1 KHz/0.001 MHz
Accuracy ± (0.5%+2d )
Sensitivity Min. 1.5 V rms, Max. 5 V rms.
Duty
Range 1 % to 99 %
Resolution 0.1 %
Accuracy ± 1% duty
Measuring signal Function switch set to " Hz " :
and level 2 Vp-p to 5 Vp-p,
square wave 10 KHz max.
Function switch set to "ACV", "ACA" :
50 Hz to 500 Hz
OHMS
Range 400/4 K/40 K/400 K/4 M/40 M ohm
Resolution 0.1/1/10/100/1 K/10 K ohm
Accuracy 400 ohm ± (0.5%+2d )
4K/40K/400K/4 M
40 M ± (2%+5d )
Over load ± 500 DCV, 350 ACV
protection
Continuity Beeper
Beeper will sound if measured resistance less than 20 ohm.
Remark :
* Spec. tested under the environment RF Field Strength less
than 3 V/M & frequency less than the 30 MHz only.
5
