2. SPECIFICATIONS
Principal The hardness of Fruit can express by the
unit area ( S ) could undertake the
pressure of dynamometer ( N) , their
specific value is just as the hardness ( P ).
P = N / S
P = Hardness value of fruit ( Kg/cm^2 )
N = Pressure of dynamometer ( N, Kg, LB )
S = Area of pressure ( m^2, cm^2 )
Display LCD ( Liquid crystal display ).
5 digits, 16 mm ( 0.63" ) digit size.
Back light.
Display Positive or Reverse direction, select by
Direction the push button on the front panel.
Function Tension & Compression (Push & Pull).
Normal force, Peak hold ( Max. load ).
Peak hold Will freeze the display value of the
Peak load ( Max. load ).
Zero Zero button can be operated both for
"normal force" or "peak hold" operation
Unit select Kg/Newton/LB.
Measure 20.00 Kg/44.10 LB/196.10 Newton.
Capacity
Resolution 0.01 Kg/0.01 LB/0.05Newton.
Min. Display 0.02 Kg/0.07 LB/0.3 Newton,
Accuracy ± (0.5 % + 2 digits), within 23± 5 .℃
* Under the test weight on 10 Kg & 20 Kg.
Update time Fast Approx. 0.2 second.
Slow Approx. 0.6 second.
Over range Display show " - - - - " when in over
Indicator range status.
Data output RS-232 serial computer interface.
2
