6. IR ( Infrared ) TEMPERATURE
MEASURING PROCEDURE
1)Power off the meter.
2)Prepare the IR Temp. probe ( optional, IR-962 ),
connect the cable plug of IR Temp. probe into the " IR
probe input socket " ( 3-18, Fig. 1 ).
3)Power on the meter.
4)Power on the IR Temp. probe.
7. RS232 PC SERIAL INTERFACE
The instrument has RS232 PC serial interface via a 3.5
mm terminal ( 3-19, Fig. 1 ).
The data output is a 16 digit stream which can be
utilized for user's specific application.
A RS232 lead with the following connection will be
required to link the instrument with the PC serial port.
Meter PC
(3.5 mm jack plug) (9W 'D" Connector)
Center Pin..........................Pin 4
Ground/shield.....................Pin 2
2.2 K
resister
Pin 5
24
