INTEGRATED AMPLIFIER L-507uX
MARKⅡ
Before Connecting
Before connecting other devices, connect the jack side of
the accessory power cable to the AC inlet of this unit.
When connecting, turn off the power supply of this unit and
the power supplies of auxiliary devices to prevent unex-
pected accidents that may be caused by noise.
How to connect power supply
Use the accessory power cable and insert the AC plug in an
outlet on the wall in the listening room.
How to connect CD player, SACD player,
D/A converter, tuner, or other devices
Connect between the output terminals of a CD player, an
SACD player, a D/A converter, a tuner, or other such input
devices and the LINE-1 input terminals of this unit with 2 (R
and L) pin-plug cables or balanced cables.
For LINE-2, LINE-3, and LINE-4 input terminals, connection
in the same fashion as the LINE-1 terminals provides the
reproduction likewise.
How to connect speakers
Connect the left-channel speaker to the SPEAKERS-L
terminal of this unit and the right-channel speaker to the
SPEAKERS-R terminal.
Securely connect the ! terminal of the speaker system to
the speaker terminal ! (red) of this unit, and the @ terminal
of the speaker system to the speaker terminal @ (black) of
this unit.
If the ! and @ terminals are reversely connected to either
of the right and left speaker systems, the acoustic phases
of the sound reproduced from the right and left speaker
systems are also reversed. In such a case, be aware that
the sound level in the low range will be reduced and the
acoustic stability will worsen, thus failing in normal stereo
playback.
