Luxman L-509X User Manual

9
INTEGRATED AMPLIFIER L-509X
5. Standby indicator (STAND BY)
Lights up when the AC plug is plugged into a wall socket
and the operation switch is set to off.
This indicator turns off when the AC plug is disconnected
from the wall socket or the operation switch is set to on.
This indicator blinks when the protection circuit is activated.
6. Remote sensor (REMOTE)
Receives signals from the accessory remote control.
7. Loudness indicator (LOUDNESS)
Lights up when the loudness switch is on.
8. Line straight indicator (LINE STRAIGHT)
Lights up when the line straight switch is on.
When the line straight switch is set to on, the subsonic,
monaural and loudness cannot be adjusted from the ac-
cessory remote control.
When one of these switches is pressed, the line straight
indicator blinks for 3 seconds to show that this unit cannot
be operated.
Adjust the subsonic, monaural or loudness after setting the
line straight switch to off.
9. Separate indicator (SEPARATE)
Lights up when the separate switch is on.
The subsonic, monaural and loudness can be toggled only
from the accessory remote control (RA-17A).

Luxman L-509X Specifications

General

Type	Integrated Amplifier
Output Power	120W + 120W (8Ω), 220W + 220W (4Ω)
Total Harmonic Distortion	0.007% (1kHz/8Ω)
Frequency Response	20Hz - 100kHz (+0, -3.0dB)
Weight	29.3 kg
Input Sensitivity / Impedance	Line: 180mV / 47kΩ
Output Voltage	1V
Dimensions	440 x 193 x 463 mm
